Guitar Wiring Diagrams for DIY Guitar Kits

Free wiring diagrams for DIY electric guitar and bass kits. Each one is a printable drawing of the pickups, pots, switch and output jack, and it lists the exact Guitar Kit World kits that use that wiring. HH, HSH, HSS, SSS, P90, mini humbucker and bass layouts, with 3-way and 5-way switching.

Never wired a guitar before? Read how to wire an electric guitar kit first, then come back and pick the diagram that matches your controls.

Nothing here matching your electronics? Send photos of your control cavity, pickups and switch to support@guitarkitworld.com and we will draw one for your build.

Still cannot find your layout?

We add diagrams to this library all the time. If you need something we have not covered yet, send photos of your control cavity, pickups and switch to support@guitarkitworld.com and we will draw one for your build. These manufacturers also publish wiring diagrams: Guitar Electronics, Seymour Duncan, DiMarzio, Fralin Pickups, Fishman and EMG.
